| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | BGL 10A-002-S49 |
| Body Style | Fork |
| Depth | 0.079" (2mm) |
| Light Source | Visible Red LED |
| Operation | Dark-ON/Light-ON |
| Output | NPN |
| Sensing Mode | Through Beam |
| Sensor Connection | M8 |
| Series | |
| Type | Fork Sensors |
| Width | 0.394" (10mm) |
Overview
Through-beam sensors are unsurpassed in their accuracy, ability to discriminate small parts and fine detail, as well as their operating reliability. The only disadvantages are in installation and setup. The goal of eliminating these objections has led to the concept of the slot sensor.
A full range of slot sensors with a variety of slot openings and dimensions ensures that virtually any sensing task can be handled while still using standard product.
Laser slot sensors are the logical extension of this proven concept. They are unbeatable when it comes to accuracy, detail discrimination and operating reliability. Balluff laser slot sensors are ideal for precise positioning as well as reliable detection of fast-moving processes and small parts. This opens a vast range of applications in robotics and automation.
